Technical parameters:
Protocol: Zigbee 3.0
Material: metal, plastic
Lamp color: matt white
Dimensions: D800 x 60mm
Hinge length: max 1200mm
Light color: 2700-6500K
Power consumption: 48W
Luminous flux: 3360 lm
Dimmable: yes
Lighting time: 50,000 hours
Power supply input voltage: AC 100-240V 50-60Hz
CRI (Ra) Color rendering index:> 86 (daylight has a value of Ra 100)
Warranty period: 3 years
Compatibility: iOS, Android, Amazon Alexa, Apple Siri shortcuts, Google Assistant, Philips HUE, TUYA, Tahoma, Lidl, Ikea.
Final adjustment of the height of the hanging chandelier.
First, install the hanging chandelier on the ceiling according to the instructions in the enclosed manual.
For the final adjustment of the luminaire height, it is sufficient to adjust the length of the suspension cables.
Cable length shortening:
1. release the lock located on the upper edge of the cable (at the base of the luminaire) by pressing inwards into the body of the base and then
2. After that, slowly slide the cable up towards the base of the luminaire. The cable remains fixed in the position you have selected.
3. Adjust all cables one by one.
Extending the cable length: if you have inserted the cable too far, you must first release it by deactivating the lock (again by pressing the locking ring inside the base of the luminaire). This will allow you to loosen the cable and then adjust it to your chosen position.
Adjust all cables one by one.
Never pull the cables forcibly, without deactivating the fuse! Mechanical damage occurs during such handling.
Thank you for your understanding
Colour | White |
Barva světla | Přírodní bílá 4000K-4500K, Studená bílá 6000K-6500K, Teplá bílá 2700K-3000K |
Délka nejdelší strany v mm | 800 mm |
Hmotnost s obalem v kg | 5,45 kg |
Materiál | Hliník, Kov, Plast |
Průměr | 800 mm |
Příkon (W) | 48 W |
Stupeň krytí | IP20 |
Členění dle místností | Jídelna, Kancelář, Kuchyň, Ložnice, Obývací pokoj |
Šířka v mm | 800 mm |
Tvar | Kulatý |
Typ instalace | Závěsné |
Typ Patice | Integrovaný LED modul |
Délka závěsu v mm | 1200 mm |
Funkce | Amazon Alexa, Dálkové ovládání, Google Assistant, Inteligentní, Kompatibilní s Philips Hue, Stmívatelné, Zigbee 3.0, Změna odstínů bílé barvy |
Rozměr balení | 900*870*190 |
Výška v mm | 0 mm |
