Technical parameters:
Protocol: Zigbee 3.0
Material: metal, plastic
Lamp color: matt white
Dimensions: D910 x 130mm
Hinge length: max 1200mm
Light color: 2700-6500K
Power consumption: 60W
Luminous flux: 4200lm
Dimmable: yes
Lighting time: 50,000 hours
Power supply input voltage: AC 100-240V 50-60Hz
CRI (Ra) Color rendering index: <86 (daylight has a value of Ra 100)
Warranty period: 3 years
If you are unable to pair the Immax NEO light with the remote control or the Immax NEO smart gate, you can find the instructions HERE
Final adjustment of the height of the hanging chandelier.
First, install the hanging chandelier on the ceiling according to the instructions in the enclosed manual.
For the final adjustment of the luminaire height, it is sufficient to adjust the length of the suspension cables.
Cable length shortening:
1. release the lock located on the upper edge of the cable (at the base of the luminaire) by pressing inwards into the body of the base and then
2. After that, slowly slide the cable up towards the base of the luminaire. The cable remains fixed in the position you have selected.
3. Adjust all cables one by one.
Extending the cable length: if you have inserted the cable too far, you must first release it by deactivating the lock (again by pressing the locking ring inside the base of the luminaire). This will allow you to loosen the cable and then adjust it to your chosen position.
Adjust all cables one by one.
Never pull the cables forcibly, without deactivating the fuse!
Thank you for your understanding
Colour | White |
light color | Natural white 4000K-5000K, Cool white 6000K-6500K, Warm white 2700K-3000K |
length of the longest side | 91 cm |
weight with packaging in kg | 8,95 kg |
material | Metal, Plastic |
diameter | 91 cm |
wattage (W) | 60 W |
degree of protection | IP20 |
division by room | Children's room, Dining room, The kitchen, Bedroom, Living room |
width | 91 cm |
shape | Special |
installation type | Hanging |
socket type | Integrated LED module |
hinge length | 120 cm |
function | Remote control, Intelligent, Dimmable, Changing shades of white |
package size | 100*98*22 |
height | 13 cm |
Lumeny | 4200 |
Compatibility | Amazon Alexa, Apple Siri shortcuts, Google Assistant, IkeaTradfri, Lidl, Philips Hue, Somfy, Tesla, Tuya (SmartLife) |
Connection type | Zigbee 3.0 |
